Technical Data:
| Max.assembling size | 400×300mm |
| Convey Belt width | 380mm |
| Saw Wheel diameter | 711mm |
| Feed Speed | 0-18m/min |
| Saw wheel lifting motor | 0.18kw |
| Saw wheel motor | 18.5kw |
| Hydraulic Pressure | 55kg/cm² |
| The distance of blade to the worktable | 3-200mm |
| dust collector tube diameter | 102mm×2 |
| Saw blade size | 4572×27×0.9mm(1’ 锯轮) 4572×41×127mm(1.3’ 锯轮) |
| Saw the road | 1.2-2.2mm |
| Overall Dimensions | 3000×1950×1850mm |
| net weight | 1900kg |
