Technical data:
| X\Y\Z Travel | 1220× 2400× 200MM |
| vacuum system | 7.5KW Air Cooling |
| spindle motor | 9KW(ATC+12)+ (5+4) Vertical Drilling |
| Drive Motor | Servo Motor |
| Tool | 3.175mm-20mm |
| Spindle speed | 6000-24000rpm/min |
| Running speed | 25m/min |
| Guide | Taiwan TBI Guide and Slider |
| Voltage | 380V/50Hz 3phase |
| Accuracy | ±0.03mm |
| Control system | SYNTEC 6MB |
| Soft | Type3/Artcam/Ucancam/Caxa/Mastercam/UG |
